| GWR-B819LS |
|
|
| GWR-B819LS Air ratchet wrench, 10,11,12,13,14,15,16,17,18,19 mm and 11/16" Hex size capacity. 80NM work torque, 150rpm. Rear exhaust |
|
|
|
|
|
| |
|
|
| |
| |
GWR-B819LS Air ratchet wrench, 10,11,12,13,14,15,16,17,18,19 mm and 11/16" Hex size capacity. 80NM work torque, 150rpm. Rear exhaust
- 10,11,12,13,14,15,16,17,18,19 mm and 11/16" Hex size capacity.
- 80NM work torque,
- speed 160rpm.
- Rear exhaust
- Ratchet wrench can be used in narrow working spaces and can fasten bolts and nuts easily.
- This special tool can be reached tight place that other air tools can not.
- Take out : First, loosen nut by wrench then take nut out with air ratchet
- Lock : Push trigger to position the nut then lock it with torque wrench
Specification (air pressure at 90PSI, 6.2Bar, 6.3kg/cm2)
| Model Number |
Hex Size |
Working Torque |
MAX. Torque |
Free Speed |
Air Consumption |
Overall Length |
Air Inlet |
Net Weight |
Sound Level |
| mm |
nm |
ft-lb |
nm |
ft-lb |
rpm |
l/min |
cfm |
mm |
inch |
P.T |
kgs |
lbs |
dB(A) |
| GWR-B819LS |
10,11,12,13,14,15,16,17,18,19 mm and 11/16" |
80 |
59 |
90 |
66 |
150 |
353 |
12.5 |
390 |
15.35 |
1/4" |
2.42 |
5.33 |
92 |
 |
| |
|
|
|
|
|
