| GWR-B808LS |
|
|
| GWR-B808LS Air ratchet wrench, 6,7,8,10,11,12 mm and 1/4" ,3/8" Hex size capacity. 10NM work torque, 180rpm. Rear exhaust |
|
|
|
|
|
| |
|
|
| |
| |
- Ratchet wrench can be used in narrow working spaces and can fasten bolts and nuts easily.
- This special tool can be reached tight place that other air tools can not.
- Take out : First, loosen nut by wrench then take nut out with air ratchet
- Lock : Push trigger to position the nut then lock it with torque wrench
|
|
|
|
Specification (air pressure at 90PSI, 6.2Bar, 6.3kg/cm2)
| Model Number |
Hex Size |
Working Torque |
MAX. Torque |
Free Speed |
Air Consumption |
Overall Length |
Air Inlet |
Net Weight |
Sound Level |
| mm |
nm |
ft-lb |
nm |
ft-lb |
rpm |
l/min |
cfm |
mm |
inch |
P.T |
kgs |
lbs |
dB(A) |
| GWR-B808LS |
6,7,8,10,11,12,1/4",3/8" |
10 |
7 |
10 |
7 |
180 |
127 |
4.5 |
300 |
11.81 |
1/4" |
1.30 |
2.87 |
86 |
|
|
| |
|
|
|
|
|
